Easy Notes Of Object oriented programming unit-1 @Computer Diploma

Description

1.1 Procedure Oriented Programming (POP) vs. Object Oriented Programming (OOP)

1.2 Features of Object Oriented Programming

The key features of OOP are:

• Encapsulation: The bundling of data (attributes) and the methods (functions) that operate on that data into a single unit, an object. It also involves data hiding, restricting direct access to an object’s internal state.
• Abstraction: Hiding the complex implementation details and showing only the essential features of an object. For example, when you drive a car, you don’t need to know how the engine works, only how to use the steering wheel and pedals.
• Inheritance: A mechanism where a new class (the derived or child class) inherits properties and behaviors from an existing class (the base or parent class). This promotes code reuse and establishes a hierarchical relationship between classes.
• Polymorphism: The ability of an object to take on many forms. It allows a single interface to be used for a general class of actions. A simple example is a + operator that can perform both addition on numbers and concatenation on strings. This is often achieved through function overloading and function overriding.

Examples of Object-Oriented Languages: Java, C++, Python, C#, Smalltalk, Ruby.

Applications of OOP:

• GUI-based applications (e.g., user interfaces for software).
• Real-time systems.
• Databases.
• Operating systems.
• Simulation and modeling systems.
• Game development.

1.3 Data Types, Variables, and Type Compatibility in C++

• Data Types: Classify the type of data that a variable can hold. C++ has built-in types like int (for integers), float and double (for floating-point numbers), char (for characters), and bool (for boolean values). It also supports user-defined types like classes and structures.
• Type Compatibility: Refers to whether one data type can be assigned to a variable of another data type without a compilation error. This is often handled by type casting or type conversion.
• Declaration of Variable: The process of specifying a variable’s name and its data type. Example: int age;. This allocates memory for the variable.
• Dynamic Initialization of Variable: The initialization of a variable at runtime, where the initial value is determined by a user or a computed expression. Example: float area = length * width;.
• Reference Variable: An alias or another name for an already existing variable. It’s declared using the ampersand &. Any changes made to the reference variable will affect the original variable. Example: int x = 10; int &ref_x = x;.
• Type Casting: The process of converting one data type into another.
  • Implicit Type Casting (automatic): Done by the compiler, usually for type promotion (e.g., int to float).
  • Explicit Type Casting (manual): Done by the programmer using a cast operator. Example: (int)3.14;.

1.4 Special Operators in C++

• Scope Resolution Operator (::): Used to define a member function outside its class, access a static member of a class, or access a global variable when a local variable with the same name exists.
• Memory Management Operators:
  • new: Used to dynamically allocate memory at runtime. For example, int *ptr = new int; allocates memory for an integer and returns a pointer to it.
  • delete: Used to deallocate memory previously allocated with new. It’s crucial for preventing memory leaks. For example, delete ptr;.
• Manipulators: Special functions used with input/output streams to format the output.
  • endl: Inserts a newline character and flushes the output buffer.
  • setw(n): Sets the field width to n for the next output operation.

1.5 Structure of a C++ Program & Basic I/O

A basic C++ program includes:

• Header Files: Provide declarations for functions and classes (e.g., <iostream> for input/output).
• main() function: The entry point of every C++ program.
• Statements and expressions: The instructions that make up the program logic.

Example of a Simple C++ Program:

#include <iostream>

int main() {
    std::cout << "Hello, World!";
    return 0;
}

Basic Input/Output Operators & Functions:

• Output Operator (<<): Used with std::cout (console output stream) to send data to the console.
• Input Operator (>>): Used with std::cin (console input stream) to read data from the keyboard.

1.6 Class & Object

• Class: A blueprint or template for creating objects. It defines a new data type with its own attributes (data members) and behaviors (member functions). It’s a logical construct; no memory is allocated when a class is defined.
• Object: An instance of a class. It’s a real-world entity created from the class blueprint. When an object is created, memory is allocated for it.

Specifying a Class: A class is defined using the class keyword, followed by the class name. The members are enclosed in curly braces.

Access Specifiers: Control the visibility and accessibility of class members.

• public: Members are accessible from outside the class.
• private: Members are only accessible from within the class itself. This is a key part of encapsulation and data hiding.
• protected: Members are accessible within the class and by derived classes.

Defining Member Functions:

• Inside Class Definition: Functions can be defined directly inside the class declaration. These are automatically considered inline functions.
• Outside Class Definition: Functions are defined outside the class using the scope resolution operator (::) to link the function definition to the class.

Creating Objects: An object is created by using the class name followed by the object name. Example: Car my_car;.

Memory Allocation for Objects: Memory is allocated for an object only when it’s created. The size of the memory allocated depends on the data members defined within the class. Member functions are stored in a common memory area and are not duplicated for each object. The object itself only holds the memory for its data members.

Keywords of this Topic: class, public, private, protected, this (a pointer to the current object), new, delete.
